Introduction
Diamond cutting is a type of cutting tool widely used for processing hard and brittle materials such as stone, concrete, precast slabs, old and new road surfaces, and ceramics.
A diamond cutting disc mainly consists of two parts: the base (steel core) and the segments. The base serves as the primary support for bonding the segments, while the segments perform the actual cutting during operation. The segments gradually wear down during use, whereas the base remains intact.
The reason the segments are able to cut is that they contain diamond particles. As the hardest known material, diamonds grind and cut the workpiece through friction. These diamond particles are embedded within the segments and are bonded by a metal matrix.
Parameter
OD（mm） | Recommended Speed | RPM | Max Cut Depth |
350 | 2592 | 5500 | 105 |
400 | 2268 | 3820 | 130 |
500 | 1814 | 3055 | 180 |
600 | 1512 | 2550 | 225 |
700 | 1296 | 2185 | 270 |
800 | 1134 | 1910 | 310 |
900 | 1008 | 1700 | 355 |
1000 | 864 | 1455 | 400 |
1200 | 756 | 1275 | 500 |
150mm diamond grooving blade, 180mm diamond slotting blade, 350mm diamond saw blade, 400mm Hengrui cobblestone cutting blade, 500mm concrete saw blade, 600mm diamond wall cutting blade, 700mm wall saw blade, 800mm diamond pile cutting blade, 900mm diamond saw blade, 1000mm diamond saw blade, 1200mm concrete saw blade.
